Optimal solutions for electrical stimulation research and applications
SXC-4S is a new multi-channel electrical stimulator designed by the authoritative team focusing on TENS (Transcutaneous Electrical Nerve Stimulation) research in China, which is powerful, high performance, non-invasive, safe and easy to control. The new multi-channel electrical stimulator is powerful, non-invasive, safe and easy to control, and can be used to activate nerves, evoke nerve impulses and trigger the sensory and tactile sensations in humans, thus conducting research and applications related to sensory/tactile sensations.
SXC-4S is easy and fast to operate, with a friendly interface display and two modes of panel control and USB external control. This allows users to achieve direct control of the stimulator through software such as E-prime MATLAB, which is convenient for users to carry out scientific experiments and is compatible with EMG/ECG/EEG/ERPS/fNIRS/MR/: on the other hand, it supports users to develop their own control software or secondary development based on this device. At the same time, SXC-4S also uniquely realizes multi-channel synchronous/asynchronous output stimulation, each channel can be independently set parameters, independent triggering, and also supports multi-channel simultaneous triggering greatly expands the application field of the electrical stimulator, improving the flexibility of the application of the stimulator can be said SXC-4S is a high-quality multi-purpose, and very cost-effective electrical stimulator. The SXC-4S is a high quality, multi-purpose and cost-effective electrical stimulator.
Compatible with multiple devices
The SXC-4S multichannel electrical stimulator supports use with a variety of research equipment (oculomotor/EEG equipment/NIR equipment, etc.) and can be programmed with E-prime/MATLAB to synchronize the electrical stimulator with other equipment. In addition, the SXC-4S supports use in the NMR environment when NMR compatible electrodes and special shielded wires are used.
Programmable powerful
SXC-45 program control capability is powerful, the user through the computer's USB interface and multi-channel electrical stimulation instrument connected to the E-prime/MATLAB environment can easily and quickly achieve effective control of the machine through the programming of the electrical stimulation instrument parameters can be set and stimulation trigger / pause / stop and other functions, greatly expanding the SXC-4S research application field early program control script Example.
Format:SET:,mode>,HF frequency Hz>,HF pulse width us>,operating time s>,.
For example, SET:CH1,1,1000,500,30,9.1 means parameter setting for channel 1, mode 1 (square wave), frequency 1000Hz, pulse width 500ps, operating time 30s, current size 9.1mA In addition to , SXC-4S also supports pulse repetition number setting. The number of pulse repetitions can be set by replacing PUL with above.
Research and application areas
- Pain Medicine
- Behavioral and brain cognitive research in the field of TENS
- Behavioral and brain cognitive studies in the haptic domain
- Social Psychology
- Management Psychology
- Analgesic
- Psychological Counseling
- Behavior modification
